PRI Gateway

PRI Gateway/Openvox



A PRI Gateway allows dialing direct routing of calls between the fixed line ISDN networks and the cost-effective IP networks for capitalizing the cost. By using the PRI Gateway with the existing PBX / PABX telephone systems, production of all types of companies will earn a huge profit and achieve substantial cost savings without any difficulties. The PRI Gateway is the way to connect the interface between the enterprise and the network for existing and new technologies.

PRI Gateways directly connect to ISDN PRI, E1 PRI, T1 PRI (T2/S2 ISDN, RDSI) interfaces of the office PBX, and enable bi-directional traffic for both VoIP and PSTN, all in one compact box. The PRI Gateway is the single -span Gateway which can offer 30 continuous VOIP to ISDN PRI calls. This in-line device sits between ISDN PBX and T1/E1 PRI line to connect PBX users to the IP network for cost-effective communication.

The PRI Gateway is more suitable for SMBs, large enterprises, VOIP service providers and system integrators for smooth working with migration to the new age IP telephony. It helps them in controlling the communication overheads and realizes that the earlier return on investment through advanced features and functionalities.


Request
  • A-116 is a 16-port E1/T1 Port Voice and Data Card
  • 480 simultaneous voice calls (or 32.8 Mbps full duplex data)

A-108

  • 8-port E1/T1 Port Voice and Data Card
  • 240 simultaneous voice calls (or 16.4 Mbps full duplex data)
  • Lifetime warranty (with product registration)

A-104

  • 4-port E1/T1 Port Voice and Data Card
  • 120 simultaneous voice calls (or 8.192 Mbps full duplex data)
  • Lifetime warranty (with product registration)

A-102

  • 2-port E1/T1 Port Voice and Data Card
  • 60 simultaneous voice calls (or 4.096 Mbps full duplex data)
  • Lifetime warranty (with product registration)

A-101

  • 1-port E1/T1 Port Voice and Data Card
  • 30 simultaneous voice calls (or 2.048 Mbps full duplex data)
  • Lifetime warranty (with product registration)

Call Routing

  • Multiple SIP registrars
  • Multilevel alternative routing
  • Black / White list
  • QoS routing

Call Manipulation

  • Header & number manipulation
  • Codec translation & transacting
  • Overlap / en-block conversion

Advanced

  • Integrated SIP registrar & location Server
  • Integrated E-SBC feature set
  • ISDN supplementary services Conversion
  • Advice of Charge (AoC) generation
  • Full IP routing & firewall capabilities
  • Remote provisioning
  • VPN
  • SNMP
